Power Voltage: Single phase AC 220V± 15% / 3 phase AC 220V± 15%. Control Model: Position, speed, torque, speed trial run, and JOG trial run. Built-in regenerative brake. Optional incremental encoder, wire-saving encoder, absolute encoder and resolver. Speed frequency response400Hz. Speed fluctuation is less than 0.03% of rated speed. Speed control ratio 1: 5000. Input pulse frequency: 0~500 KHz. Applicable for servo motor with less than 5 times moment of inertia. Strong protection function, abundant control models and higher performance. Servo Motor Feature: 1. The max torque is up to 300% of rated torque. 2. The max current is up to 300% of rated current. 3. The max speed is up to 4500rpm. 4. Be used to drive the feed shaft of various machineries. 5. Various models (200W~22KW, with brake etc). 6. Standard mounted wire-saving encoder 2500rpm, optional absolute encoder 131072rpm or resolver. 7. Standard protection configuration is IP65. 8. The malfunction ratio is less than 0.01% within 18 months warranty
